YP20G
YP系列水泵 ● 大流量、高揚程、低噪音、低油耗，抽水性能優異 ● 采用高性能四沖程OHV汽油發動機，配備機油報警裝置 ● 使用操作便利舒適，經濟耐用，在嚴苛作業環境下亦能****運作。
產品詳情
|
Specification sheet 規格表 |
|
|
Modle 型號 |
YP20G |
|
PUMP 泵體： |
|
|
Pump type 泵體結構 |
Single stage, single suction, coaxial direct connec-tion, high speed centrifugal self suction type 單級、單吸、共軸直聯、高速離心自吸式 |
|
Inlet/outlet port diameter (mm) 進/出水口直徑 |
50 |
|
Max. capacity (l/min) ****流量 |
600 |
|
Tax.head(m) ****揚程 |
30 |
|
Max.suction head(m) ****自吸高度 |
7 |
|
Limited self-suction time(s) 規定自吸時間 |
120 |
|
Impeller 葉輪 |
Semi-open structure 半開式 |
|
Connection port 連接口 |
Outer pipe thread 外管螺紋 |
|
GASOLINE ENGINE 汽油機： |
|
|
Modle 型號 |
GT175 |
|
Displacement 排量（cm³） |
171 |
|
Rated output 額定輸出 |
3.3kW/3600rpm |
|
Fuel tank availability capacity(l) 燃油箱有效容積 |
4.5 |
|
Fuel standard--Fuel consumption 燃油規格--燃油消耗 |
Vehicle unleaded gasoline--1.7l/Hr 車用無鉛汽油 |
|
Starting system 起動方式 |
Recoil starter 手拉反沖起動 |
|
Protection system 保護系統 |
Low oil level protection 低油位保護 |
|
Noise level 噪聲 |
≤71dB(A) |
|
Pumassembly configuration 泵組結構 |
Portable frame structure 輕便框架結構 |
|
Net.Weight (Kg) 凈重 |
28 |
|
Dimension (LxWxH mm) 尺寸 |
515*395*450 |
|
535*415*470 |
|
|
Sand strainer 沙石過濾器 |
● |
|
Throat collar 喉箍 |
● |
|
Rubber foot mount 橡膠腳墊 |
● |
|
Hose joint 管接頭 |
● |
|
O-ring or Gasket O型圈或密封墊 |
● |
|
Spark plug sleeve 火花塞套筒 |
● |
|
OWNER'S MANUAL 用戶手冊 |
● |
|
Performanc,Quality and standard 性能、品質與標準 |
|
|
|
Techno-standard of the gasoline engine water-pump is according to GB/T 24673-2009, JB/T 6664－2017. The machinery safety is according to GB 10395.8-2006. 汽油機水泵技術標準執行 GB/T 24673-2009, JB/T 6664－2017. 機械安全按照 GB 10395.8-2006. |
